Size table · 240 part numbers
Find the right size.
Size to the cable armor's outside diameter (not the jacket). Filter by series or trade size, or type an armor O.D. to find the row that covers it. All measurements in inches.
Material
303 stainless is our standard stainless. 316 stainless (S6) and other options are also available — call (817) 527-1635 or email for a quote.
AluminumWT 118-100
StainlessWT 118-100 S3
- WT — the series.
- 118 — top of the armor range in hundredths of an inch (fits 1.110–1.180″).
- 100 — hub (NPT trade) size. 050 = ½″, 075 = ¾″, 100 = 1″ … 500 = 5″.
- F — (option) fine-lead scroll, the thread that grips the cable armor (typically interlock cable).
- S3 — stainless. Aluminum parts stop at the size; stainless adds S3 (303 stainless). S6 means 316 stainless, quote only.
Material
| Catalog number | NPT | Armor O.D. | Jacket O.D. (reference only) |
Conn. dia. | Assembled length |
|---|
Jacket O.D. is for reference only — size to the armor O.D.
† Assembled length is ½″ shorter on the F connectors. Spec sheets available on request — contact us.
Call or message us for additional sizes and options.
